How to Configure firewalld on CentOS, Rocky Linux and AlmaLinux

firewalld is the firewall of CentOS, Rocky Linux, AlmaLinux and RHEL: zones, services and ports, permanent rules, SSH for one address, common errors.

3 min readBy Smita

Reviewed by the AmazingRDP technical team

Configuring firewalld on CentOS

A server to secure your way. A Linux VPS gives you root access. See Linux VPS from $6.99

firewalld is the firewall manager on the Red Hat family of systems: RHEL, CentOS Stream, Rocky Linux, AlmaLinux and Fedora. It is controlled with one command, firewall-cmd, and built around two ideas: zones and the difference between runtime and permanent rules. Once those are clear, the rest is short.

A note on the name in the title: CentOS Linux 7 and 8 are no longer maintained. Everything here applies unchanged to their successors: see Rocky Linux vs CentOS.

Is it running?

sudo firewall-cmd --state
sudo systemctl enable --now firewalld

If it is not installed: sudo dnf install firewalld. Over SSH there is no risk in starting it; the default zone allows SSH.

See what is allowed

sudo firewall-cmd --list-all

This shows the active zone, the interfaces in it, and the services and ports it lets in. Everything not listed is refused.

Runtime and permanent

This is the part that catches everyone once.

  • A command without --permanent takes effect at once and is forgotten at the next reload or restart.
  • A command with --permanent is saved and does nothing until you reload.

So the normal pattern is two lines:

sudo firewall-cmd --permanent --add-service=https
sudo firewall-cmd --reload

The other way round also works: try rules without --permanent, and when they are right, keep them all with sudo firewall-cmd --runtime-to-permanent. That is the safer habit on a remote server, since a mistake disappears with a restart.

Services and ports

sudo firewall-cmd --get-services
sudo firewall-cmd --permanent --add-service=http
sudo firewall-cmd --permanent --add-port=8080/tcp
sudo firewall-cmd --permanent --add-port=5000-5010/udp
sudo firewall-cmd --permanent --remove-service=cockpit
sudo firewall-cmd --reload

A service is a name for one or more ports (http is 80, https is 443). Use the name where one exists and the port number otherwise.

Zones

A zone is a set of rules for a level of trust. Every network interface belongs to one zone.

ZoneLets in by default
public (the default)SSH and little else
home, internal, workA few more services for trusted networks
trustedEverything
dropNothing; no answer is sent
blockNothing; a refusal is sent
sudo firewall-cmd --get-active-zones
sudo firewall-cmd --get-default-zone
sudo firewall-cmd --zone=internal --list-all

A server with one interface on the internet needs only public. Zones earn their keep when a server has a second, private interface.

Allow something for one address only

The cleanest way is to put the trusted address into a zone of its own:

sudo firewall-cmd --permanent --zone=internal --add-source=203.0.113.25
sudo firewall-cmd --permanent --zone=internal --add-service=ssh
sudo firewall-cmd --permanent --zone=public --remove-service=ssh
sudo firewall-cmd --reload

SSH now answers only that address. Before the last two lines, be certain the address is yours and does not change, and keep the provider's console within reach.

The same can be written as a "rich rule":

sudo firewall-cmd --permanent --add-rich-rule='rule family=ipv4 source address=203.0.113.25 port port=3306 protocol=tcp accept'

Block an address

sudo firewall-cmd --permanent --zone=drop --add-source=198.51.100.7
sudo firewall-cmd --reload

If you lock yourself out

Open the server's console in the provider's control panel and run sudo firewall-cmd --add-service=ssh. If the bad rule was not permanent, a restart of the server also clears it.

Problems

SignCause
The rule vanished after a restart--permanent was missing
The rule was added and nothing changed--reload was missing
The port is open and still not reachableNo program is listening on it, or it listens on 127.0.0.1 only: see listing open ports on Linux. A provider firewall may also sit in front
A service on an unusual port is refused although the firewall allows itSELinux; the audit log names it
ALREADY_ENABLEDA warning only: the rule exists

The Ubuntu counterpart is ufw: open or block a port in the Ubuntu firewall. A web server behind this firewall: HTTPS for Nginx with Let's Encrypt. Moving SSH to another port is covered for Ubuntu in changing the SSH port. For a server of your own, see our Linux VPS plans.

Questions

How do I open a port in firewalld?

Run sudo firewall-cmd --permanent --add-port=8080/tcp and then sudo firewall-cmd --reload.

What is the difference between runtime and permanent rules?

Runtime rules apply at once and are lost on reload or restart. Permanent rules are saved and apply after a reload.

What is a zone in firewalld?

A named set of rules for a level of trust. Each network interface or source address belongs to one zone.

How do I see the current firewalld rules?

Run sudo firewall-cmd --list-all.
