When a Linux server feels slow, there are only four things it can be short of: processor time, memory, disk speed or network. The tools below show which one. All of them are free and run in a terminal.
htop: the overview
sudo apt install htop
htop
On CentOS, Rocky and Fedora: sudo dnf install htop.
Reading the top of the screen
- One bar per processor core. Green is ordinary programs, red is the kernel, and on a virtual server a further colour can show "steal": time your VPS wanted and the host gave to someone else.
- Mem. Green is memory used by programs. Blue and yellow are buffers and cache, which Linux gives back the moment a program needs them. A nearly full bar that is mostly cache is healthy.
- Swp. Swap in use. A little is harmless; swap that keeps growing while the server is slow means memory is short.
- Load average. Three figures for the last 1, 5 and 15 minutes: how many tasks were running or waiting. Compare them with the number of cores. On four cores, a load of 4 is full use; 8 means tasks queue.
Keys worth knowing
| Key | Does |
|---|---|
F6 or P / M | Sort by a column; by processor; by memory |
F5 or t | Tree view: which process started which |
F4 / F3 | Filter / search by name |
u | Show one user's processes |
F9 | Send a signal: 15 asks a process to end, 9 forces it |
H | Hide or show threads |
q | Quit |
top: always there
top is installed on every system. Press 1 for one line per core, M to sort by memory. The line %Cpu(s) has two fields that htop makes less obvious: wa, time spent waiting for the disk, and st, steal.
vmstat: the trend
vmstat 2 10
Ten lines, one every two seconds. Watch r (tasks waiting for a core), si and so (memory moving in and out of swap; anything but zero for long is bad), and wa.
Disk: iostat and iotop
sudo apt install sysstat iotop
iostat -xz 2
sudo iotop -o
iostat shows each disk: %util near 100 with a rising await means the disk is the bottleneck. iotop -o shows which process is doing the reading and writing.
Memory in one line
free -h
Read the column available, not free. Available is what programs can still get, counting cache that would be released.
Network
sudo apt install nload
nload
Shows traffic in and out per interface. For traffic per process, nethogs does the same job.
Which tool for which question
| Question | Tool |
|---|---|
| What is using the processor or memory right now? | htop |
| Is the server swapping? | vmstat 2, free -h |
| Is the disk the bottleneck, and who is writing? | iostat -xz 2, iotop -o |
| How busy was it last night? | sar (from sysstat, once its collection is switched on) |
| How full are the disks? | df -h |
Reading the result
- All cores full, load above the core count: the work needs more processor, or one program has run away. htop names it.
- Swap growing,
si/sobusy: not enough memory. - High
wa, cores idle: the disk is too slow for the work. - High
ston a VPS: the host is busy; nothing inside your server will fix it.
What to do about each is in ways to make a VPS faster; a desktop that locks up is covered in why Ubuntu freezes. When the server is simply too small for the work, see our dedicated servers.
Questions
How do I install htop?
On Ubuntu and Debian: sudo apt install htop. On Rocky, CentOS and Fedora: sudo dnf install htop.
What does load average mean?
The average number of tasks running or waiting over 1, 5 and 15 minutes. Compare it with the number of processor cores.
Why is my memory almost full in htop?
Linux uses spare memory as disk cache and releases it when programs need it. Look at "available" in free -h.
How do I see which process uses the disk?
Run sudo iotop -o.
