What Is MikroTik? RouterOS, RouterBOARD and the Cloud Hosted Router Explained

MikroTik makes router hardware and RouterOS, the system that runs on it. What RouterOS does, its licence levels, and the Cloud Hosted Router on a server.

3 min readBy Smita

Reviewed by the AmazingRDP technical team

What MikroTik is and what it is used for

RouterOS can run on a machine of its own. Ask support before ordering which systems a dedicated server can be installed with. See Cheap Dedicated Servers from $38.99

MikroTik is a Latvian company, founded in 1996, that makes networking equipment and the software that runs on it. Its products are popular with internet providers, offices and enthusiasts because they offer features found in far more expensive gear. Three names come up again and again, and they mean different things.

NameWhat it is
RouterOSThe operating system: routing, firewall, VPN, wireless, traffic shaping and much more
RouterBOARDMikroTik's own hardware: routers, switches and wireless devices that run RouterOS
CHR (Cloud Hosted Router)RouterOS packaged to run as a virtual machine
WinBoxThe small Windows program for managing RouterOS devices graphically

What RouterOS does

  • Routing: static routes and the dynamic protocols providers use (OSPF, BGP).
  • Firewall and NAT: filtering, port forwarding, address lists. See port forwarding with WinBox and blocking websites on MikroTik.
  • VPN: WireGuard, IPsec, OpenVPN, L2TP and others, as server or client.
  • Traffic control: queues that limit or prioritise speed per user or service.
  • Hotspot and user management: login pages for guest networks, PPPoE for provider customers.
  • Wireless: access points and long point-to-point links.
  • Tools: bandwidth test, packet sniffer, scripting and a scheduler.

How it is managed

  • WinBox, the graphical tool most administrators use.
  • WebFig, the same menus in a browser.
  • The command line, over SSH or the console. Every setting is a short command, which makes configurations easy to save and repeat.
  • An API, for automation.

What it is used for

UserTypical use
Small internet providersCustomer connections, speed plans, BGP to upstream networks
OfficesRouter and firewall, VPN between branches, guest Wi-Fi
Home enthusiastsA router with far more control than a consumer model
Server administratorsCHR as a virtual router or VPN endpoint in front of other servers

The Cloud Hosted Router

CHR is RouterOS built for virtual machines. It runs on the common hypervisors (KVM, VMware, Hyper-V, VirtualBox) and behaves like a hardware MikroTik with virtual network ports. People use it as a VPN concentrator, as a router between private networks, or to learn RouterOS without buying a device.

CHR licences

LicenceSpeed limit per interface
Free1 Mbit/s upload; fine for learning
P11 Gbit/s
P1010 Gbit/s
P-unlimitedNo limit

A 60-day trial of the paid levels is available from MikroTik with a free account. Hardware devices use a different scheme, "levels" 3 to 6, and the licence comes with the device. Prices and terms are on MikroTik's site; check there before you plan.

Running CHR on a rented server

  • It replaces the operating system of the machine or virtual machine. It is not a program you install on Windows or Ubuntu.
  • It needs a way to be installed: a custom image or ISO, or a rescue system from which the disk image is written. Whether that is possible depends on the provider and the plan. Ask our support before ordering if CHR is what you want to run; we do not list it among the standard systems.
  • To learn, you need no server at all: CHR runs in VirtualBox on your PC with the free licence. See setting up a virtual lab.

Secure it from the first minute

MikroTik devices open to the internet with default settings have been hijacked in large numbers and used in botnets. On any RouterOS installation:

  1. Set a strong password for admin, or better, create your own user and disable admin.
  2. Under IP, Services, disable what you do not use (Telnet, FTP, the old API) and restrict WinBox and SSH to your own addresses.
  3. Keep RouterOS updated: System, Packages, Check For Updates.
  4. Add firewall rules that drop unsolicited traffic from the internet to the router itself.

MikroTik or something else?

MikroTikTypical alternative
Price for the featuresLowEnterprise brands cost several times more
Learning curveSteep; nothing is hidden, little is automaticConsumer routers are simpler and far less capable
As a software firewall on a serverCHRpfSense or OPNsense (free, web-based), or plain Linux with nftables

For a whole machine to run network software on, see our dedicated servers, and ask first which systems can be installed.

Questions

What is MikroTik used for?

Routing, firewalling, VPNs, traffic shaping and wireless networks, by internet providers, offices and enthusiasts.

What is RouterOS?

MikroTik's operating system for routers. It runs on MikroTik hardware and, as the Cloud Hosted Router, in virtual machines.

Is MikroTik CHR free?

The free licence limits upload to 1 Mbit/s per interface. Paid licences lift the limit; a 60-day trial is available.

Can I install MikroTik on a VPS?

Only where the provider lets you install a custom system image. Ask before ordering.
