How to Live Stream in 4K to YouTube with OBS on a Remote Server
Set up OBS Studio for a 4K live stream to YouTube from a remote Windows server: what the server needs, the video and encoder settings, and the YouTube side.
3 min readBy Soumya
Reviewed by the AmazingRDP technical team

Streaming around the clock from a server? See our Streaming RDP plans. See Streaming RDP from $15.99
A 4K stream is four times the picture of 1080p, and it asks four times as much of the encoder and the upload line. A remote server in a datacentre has the line. Whether it has the encoding power depends on the plan. This guide covers what is needed and every setting in OBS Studio and YouTube.
What you need
- Upload speed. A 4K stream sends tens of megabits every second, without a break. Datacentre lines handle that; most home lines do not.
- An encoder that keeps up. A graphics card with a hardware encoder (for example NVIDIA NVENC) is the comfortable way. Encoding 4K on the processor alone needs a strong one with many cores, and a faster preset.
- A working graphics adapter. OBS draws its picture with the graphics system; on a server without one it may not start.
- A YouTube channel with live streaming switched on. The first activation can take up to 24 hours, so do it a day early.
- OBS Studio from obsproject.com. Some of our Streaming RDP plans come with it installed.
1. Add your source
In OBS, click + under Sources. For a video file choose Media Source, browse to the file and tick Loop if it should repeat. For a playlist of files use VLC Video Source (it appears when VLC is installed). The source should itself be 4K; enlarging a 1080p video gains nothing.
2. Video settings
Open File, Settings, Video:
| Setting | Value |
|---|---|
| Base (Canvas) Resolution | 3840x2160 |
| Output (Scaled) Resolution | 3840x2160 |
| Common FPS Values | 30 (60 only if the source is 60 and the server keeps up) |
3. Output settings
Under Output, set Output Mode to Advanced and open the Streaming tab:
| Setting | Value |
|---|---|
| Video Encoder | The hardware encoder of your card, for example NVIDIA NVENC H.264 or HEVC. Without a card: x264 |
| Rate Control | CBR |
| Bitrate | From YouTube's table for your resolution and frame rate (see below) |
| Keyframe Interval | 2 s |
| Preset (x264 only) | veryfast or faster, to keep up at 4K |
YouTube publishes recommended bitrates on its help page for live encoder settings, and they change now and then. As a guide, 4K at 30 frames per second needs roughly 15 to 30 Mbit/s with H.264, and 4K at 60 frames clearly more; HEVC and AV1 reach the same quality with less. Audio: AAC at 128 kbit/s or more.
4. The YouTube side
- In YouTube Studio click Create, Go live, and choose the Stream tab.
- Enter the title, description and visibility.
- Under Stream latency choose Normal latency. The low-latency options limit the resolution, and 4K is not offered with the lowest one.
- Copy the stream key. Treat it like a password: anyone who has it can stream to your channel.
5. Connect OBS and go live
In OBS open Settings, Stream, choose YouTube - RTMPS as the service and either connect your account or paste the stream key. Click Start Streaming. YouTube Studio shows the preview after a few seconds and a Stream health line.
Check that it holds
In OBS, open View, Stats:
- Dropped frames (network) above zero and rising: the bitrate is too high for the line. Lower it.
- Skipped frames due to encoding lag: the encoder cannot keep up. Use the hardware encoder, a faster preset, 30 instead of 60 frames, or 1440p.
- Frames missed due to rendering lag: the graphics side is overloaded. Remove filters and extra sources.
Things specific to a remote server
- Leaving the session. Signing out ends OBS, and a plain disconnect can freeze the picture. See how to keep OBS streaming after closing RDP.
- Sound. A server may have no audio device. See how to enable audio in Windows Server 2022.
- Which plan. Our Streaming RDP plans are made for streaming. The two entry plans have no separate graphics card and work with the graphics built into the processor, which suits 1080p well. The plans above them have a graphics card. For 4K, choose one of those, or see GPU RDP and GPU dedicated servers, and ask support which card a plan has before you order.
- Rights. Stream only material you own or are licensed to show. YouTube removes streams for copyright reasons, and our usage policy says the same.
Related: streaming from a Chromebook and GPU encoding vs CPU encoding.
Questions
What bitrate do I need for a 4K stream on YouTube?
Follow the table on YouTube's help page for live encoder settings. As a guide, 4K at 30 frames needs roughly 15 to 30 Mbit/s with H.264.
Do I need a graphics card to stream in 4K?
It is strongly advisable. A hardware encoder handles 4K easily, while encoding on the processor alone needs a strong one.
Which OBS resolution settings are right for 4K?
Set both the base and the output resolution to 3840x2160.
Why does my 4K stream show as 1080p?
The output resolution in OBS is lower than 3840x2160, or a low-latency setting on YouTube limits the resolution.
