How to Fix the Black Screen in OBS Window Capture

OBS shows a black box instead of the window you want to capture? Eight fixes, from the capture method to the graphics card, in the order to try them.

3 min readBy Smita

Reviewed by the AmazingRDP technical team

Fixing the OBS window capture black screen

OBS already installed, on a server that streams while your PC is off. See the Streaming RDP plans. See Streaming RDP from $15.99

You add a Window Capture source in OBS Studio, pick the window, and the preview stays black. The sound may work; the picture does not. The cause is nearly always the way OBS tries to grab that particular window. Work through these fixes in order; most people are done after the first two.

1. Change the capture method

Double-click the Window Capture source. Under Capture Method choose Windows 10 (1903 and up) in place of Automatic or BitBlt.

MethodWorks with
BitBltOld-style programs. Shows black for anything drawn by the graphics card
Windows 10 (1903 and up)Nearly everything, browsers and modern apps included. Draws a yellow border around the captured window on some Windows versions

2. For browsers and chat apps: switch off their hardware acceleration

Chrome, Edge, Discord, Spotify and similar programs draw with the graphics card, which BitBlt cannot see. If the new capture method is not available, switch acceleration off in the program itself: in Chrome and Edge under Settings, System, then restart the program.

3. For games: use Game Capture

Window Capture is the wrong source for most games. Add a Game Capture source and set Mode to Capture specific window. If a game still shows black, run it in borderless-window mode.

4. Do not capture a minimised window

A minimised window is not drawn, so there is nothing to capture. Leave it open; it may sit behind other windows.

5. On laptops with two graphics chips: put OBS on the right one

If OBS runs on one chip and the window on the other, the capture is black. In Windows, open Settings, System, Display, Graphics, add obs64.exe, and set it to High performance for Game Capture, or Power saving if you mainly capture windows and the desktop.

6. Run OBS as administrator

A program running with administrator rights cannot be captured by one without. Right-click the OBS shortcut, Run as administrator.

7. Try Display Capture

If one window refuses, capture the whole screen with a Display Capture source and crop it: hold Alt and drag the edges of the source in the preview.

8. Update, and check for protected content

  • Update OBS and the graphics driver.
  • Films and series from streaming services are protected against capture and show black on purpose. That is not a fault, and there is no setting for it.
  • A few programs, some banking and conferencing tools among them, mark their windows as not capturable.

Quick table

What is blackTry first
A browserFix 1, then 2
A gameFix 3
Everything, on a laptopFix 5
One program that runs as administratorFix 6
A film from a streaming serviceNot fixable (fix 8)

Black screen on a remote desktop

On a server reached by Remote Desktop there are two more causes.

  • The capture goes black when you disconnect. When the Remote Desktop window closes, Windows stops drawing the session. The cure is to hand the session to the server's console before leaving: see keeping OBS streaming after closing RDP.
  • No graphics card. A server without one draws everything in software, and some capture methods and all hardware encoders are missing. Use the method from fix 1 and the software (x264) encoder. Which of our streaming plans have a graphics card is on the plan page; see also streaming in 4K with OBS.

Where streams can be sent from a desktop is listed in live streaming platforms. A desktop with OBS installed that runs day and night: Streaming RDP.

Questions

Why is OBS window capture black?

Usually because the capture method cannot see windows drawn by the graphics card. Set Capture Method to "Windows 10 (1903 and up)".

How do I capture Chrome in OBS without a black screen?

Use the Windows 10 capture method, or switch off hardware acceleration in Chrome's System settings.

Why is Netflix black in OBS?

Streaming services protect their video against capture. This is intended and cannot be switched off.

Why does OBS go black when I close Remote Desktop?

Windows stops drawing a disconnected session. Hand the session to the console before disconnecting.
